MLP MiniBook
Desktop decentralized MLP personalization solution for ePassport issuance.
The MLP MiniBook is a compact desktop system that personalizes polycarbonate datapage ePassports with the Multi-Layer Personalization security process. It reaches the same quality as the centralized MLP ProBook in a footprint that fits an issuing office, which makes it suited to small and medium-volume programmes and to decentralized issuance networks.
60 UPH
Production speed
600 dpi
Laser engraving
1200 dpi
UV inkjet printing
ICAO 9303
Standard compliance
Full MLP personalization on a desktop footprint
Multi-Layer Personalization
The same MLP security process as the larger systems, reaching the quality of the centralized MLP ProBook.
What's MLP colour printing?ICAO-Compliant ePassports
Produces highly secure ICAO 9303-compliant ePassports with a true colour photo on the data page.
Colour Observation Page
Optional colour personalization of the observation page, including colour image printing.
Advanced Laser Engraving
256 grey-scale engraving with MLI up to 25°, plus embossed Braille, tactile and micro text.
Personalization Protection Layer
A protection layer over the personalized data, with varnishing that carries its own security feature.
Automatic Ink Cleaning
The print heads clean themselves automatically, keeping print quality stable between batches.
Security and colour on one datapage
Laser engraving with 256 grey levels, MLI, embossed Braille and micro text combine with full-color UV printing on the polycarbonate datapage, and the paper observation page can carry matching colour. Register cameras position each process, and a protection layer with security varnish seals the personalized data.
Technical specification
Modules
4 items
- Input module
- Capacity: 20 booklets (34 pages)
- Empty detection
- Laser module & encoding
- Fibre laser, 20 W average power, air-cooled
- Wavelength 1064 nm, M² < 1.5
- 256 grey-scale engraving, MLI up to 25°
- Embossed Braille, tactile and micro text
- 1 × register camera for positioning and register OCR for PSN
- Contactless chip encoding reader, ISO 14443 type A/B
- UV printing module
- 5-color (CMYK + varnish) inkjet, full-range colour portraits
- 600 dpi standard, up to 1200 dpi
- Varnishing with security personalization feature
- Data page and observation page printing
- 1 × register camera for printing positioning
- Output module
- Capacity: 20 booklets (34 pages)
- Full detection
System
7 items
- Operating system
- Windows 11 or above
- Connectivity
- LAN
- Dimensions
- 801 × 765 × 545 mm (L × W × H)
- Power supply
- 100–240 V AC ±10%
- 50–60 Hz ±2 Hz
- Less than 1 kW
- Operating environment
- Temperature 25 ±3 °C (recommended)
- Humidity 40–70% RH, no condensation
- Storage environment
- Temperature 5–40 °C
- Humidity 20–80% RH, no condensation
- Warranty
- 1 year
Ink
3 items
- Ink palette
- Cyan, magenta, yellow, black, varnish
- Cartridge fill volume
- 200 ml each colour
- Expiration date
- 12 months from manufacturing date
